    2022 Top Quality UV Laser Marking Machine for Sale

    Model:
    Views: 1062 Views
    Brand:
    Rating:
    0 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 5
    (0 votes, average: 0.00 out of 5, rated)
    Standard Price: $ / Set
    Price Range: $ to $ / Set According to Configurations
    Supply Ability:  Sets / Month In stock!
    Payment Terms: T/T(Telegraphic Transfer), Mastercard, Visa, e-Checking

    Get A Free Quote

    x

    Product Introduction

    Buyer's Reviews

    UV laser marking machine can clearly mark all plastics and other materials that have adverse reactions to heat, and is especially suitable for marking food, pharmaceutical packaging materials, drilling micro-holes, high-speed division of glass materials and complex processing of silicon wafers. Graphic cutting and other application fields. TPLaser provide best UV Laser marking machine.

    Demonstration Video

    Product Descriptions

    UV laser marking machine has the advantages of short wavelength, short pulse, excellent beam quality, high precision, high peak power and so on. Therefore, the system has excellent application characteristics in the field of special material processing. It can significantly reduce the thermal effect on the surface of various materials, and the processing accuracy is greatly improved.

    Advantages of UV Laser Marking Machine

    1.Reduce product damage

    The heat-affected zone of the UV laser marking machine is small, so it can avoid damage to the processed material.

    2.Fine engraving

    The spot diameter of a laser is greatly affected by the wavelength of the light. The UV wavelength (355 nm) is 1/3 of the fundamental wavelength (1064 nm), so the spot size can be reduced and marking can be performed even in a limited space

    3.Fast marking speed

    UV laser marking machine has high average power and high repetition frequency, so the marking speed is faster, which can effectively improve production efficiency.

    UV laser marking machine is small in size, low in power consumption, stable in overall performance, has considerable practicability and reliability, and is suitable for marking in many situations with high requirements such as fine graphics and text

    Applications of UV Laser Marking Machine

    The scope of application includes: flexible pcb board marking and dicing; silicon wafer micro-hole and blind-hole processing; LCD liquid crystal glass two-dimensional code marking, glassware surface drilling, metal surface coating marking; plastic buttons, electronic components , gifts, communication equipment, building materials and other materials marking.

    Almost all plastic types can be engraved with UV laser technology, including polyethylene (PE), polyvinyl chloride (PVC), polypropylene (PP), polystyrene (PS), polylactic acid (PLA), polycarbonate ( PC), acrylic (PMMA), acetal (polyoxymethylene, POM), nylon (PA), ABS (acrylonitrile butadiene styrene) and other materials.

    UV laser markers can also engrave and mark metals, but not always with the same results as fiber laser markers. Fiber lasers can etch deep and sharp effects on metal surfaces, while UV lasers have problems etching metals covered with paint or highly reflective metals like copper. Metal materials that can be engraved by UV laser technology include aluminum, gold, platinum, silver, titanium, brass, stainless steel, etc.

    The UV laser marking machine can also engrave and mark wood materials such as mahogany, walnut, oak, birch, maple, cherry, pine, spruce, cedar, fir, larch, MDF, plywood and fiberboard . In addition, it can process garments rich in synthetic fibers, including glass and cardboard.

    Specifications of UV Laser Marker

    Model TPJ-5W
    Laser Type Ultraviolet laser
    Laser Wavelength 355nm
    Output Power 3w/5w
    Pulse Length <20ns@50khz
    Marking Area 50*50mm(100*100mm)
    Min Line Width 0.01mm
    Min Character 0.2mm
    Support Voltage 220v/1phase/50hz
    Cooling Way Water cooling

    Service and Support:

    1.Delivery method: LCL or FCL, according to customer requirements

    2.After-sale service:

    ① The quality guarantee period of the whole machine is 3 years.

    ②. During the warranty period, if the equipment fails due to the manufacturing quality of the equipment provided by the seller, the seller will provide free accessories and assist the buyer to solve the problem;

    ③. During the warranty period, when the equipment fails due to improper use by the buyer, the seller will help to troubleshoot, repair or replace the parts. If the parts need to be replaced, the cost will be charged as appropriate.

    ④. After the expiration of the warranty period, lifelong service is guaranteed.
